Ductile Iron Diaphragm Type Adjustable Pressure Reducing and Stabilizing Valve for Fire Fighting Water Direction Adjustment

Name: Ductile Iron Diaphragm Type Adjustable Pressure Reducing and Stabilizing Valve for Fire Fighting Water Direction Adjustment
Brand: Shanghai Jianggong Valve Manufacturing Co., Ltd.
SKU: YX8741X-JGPV
Price: 171.90 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: JGPV

Model Number: YX8741X-JGPV

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: USD75.9/Set - 269.9/Set

Packaging Details: Plywood box safety packing

Delivery Time: 14 days

Payment Terms: L/C,T/T,Western Union

Supply Ability: 1000pcs per month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                ductile iron fire fighting valve, adjustable pressure reducing valve, diaphragm type water direction valve


Standard Or Non-standrd:	Standard	Application:	General
Product Function:	Fire Fighting Water Direction Adjustment	Construction:	Diaphragm
Working Temperature:	Normal Temperature	Pressure Application:	Nomal Pressure
Power:	Hydraulic	Manufacturing Craft:	Casting
Body Material:	Ductile Iron	Quality Warranty:	18 Months

Standard Or Non-standrd:	Standard
Application:	General
Product Function:	Fire Fighting Water Direction Adjustment
Construction:	Diaphragm
Working Temperature:	Normal Temperature
Pressure Application:	Nomal Pressure
Power:	Hydraulic
Manufacturing Craft:	Casting
Body Material:	Ductile Iron
Quality Warranty:	18 Months

Ductile Iron Diaphragm Type Adjustable Pressure Reducing and Stabilizing Valve for Fire Fighting Water Direction Adjustment

Diaphragm Type Adjustable Pressure Reducing Valve And Stabilizing Valve Ductile Iron

Product Overview

Ductile Iron Diaphragm Type Adjustable Pressure Reducing And Stabilizing Valve

Fire fighting valve products are control accessories on industrial and building pipelines. These valves are the most important controlled accessories, typically consisting of valve body, opening and closing mechanism, and valve cover. They feature simple structure and reliable sealing performance.

Most fire valves utilize clamp connections, simplifying the complex valve installation and pipeline connection process, making it fast and convenient. This represents a significant advancement in pipeline connection technology.

Technical Specifications

Parameter	Specification
Nominal Diameter DN (mm)	65~200
Nominal Pressure PN (MPa)	1.6/2.5
Test Pressure (MPa) - Strength (water)	2.4/3.8
Test Pressure (MPa) - Enclose (Water)	1.8/2.8
Working Temperature	0~80℃
Suitable Medium	Water

Product Features

High sensitivity, safety and reliability, easy debugging, and long service life
Stable pressure control with continuous pilot valve and main valve operation
Downstream pressure changes continuously and steadily with minimal influence from inlet pressure
Filter should be installed in front of the valve for easy discharge of pollutants

Application Benefits

The YX8741X diaphragm adjustable pressure reducing and stabilizing valve is used in parallel water supply systems for firefighting and domestic use. During fire emergencies, it automatically cuts off domestic water to ensure sufficient fire water supply. When fire water pressure decreases, the valve automatically opens to restore domestic water supply, eliminating the need for separate fire-fighting water supply networks and significantly reducing construction costs and water consumption.
