Product Details
Place of Origin: CHINA
Brand Name: JGPV
Model Number: D381X-JGPV
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: USD19.9/Set - 59.9/Set
Packaging Details: Plywood box safety packing
Delivery Time: 14 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000pcs per month
Standard Or Non-standrd: |
Standard |
Application: |
General |
Product Function: |
Fire Fighting Flow Control |
Construction: |
Butterfly |
Working Temperature: |
Normal Temperature |
Pressure Application: |
Nomal Pressure |
Power: |
Hydraulic |
Manufacturing Craft: |
Casting |
Body Material: |
Ductile Iron |
Quality Warranty: |
18 Months |
Standard Or Non-standrd: |
Standard |
Application: |
General |
Product Function: |
Fire Fighting Flow Control |
Construction: |
Butterfly |
Working Temperature: |
Normal Temperature |
Pressure Application: |
Nomal Pressure |
Power: |
Hydraulic |
Manufacturing Craft: |
Casting |
Body Material: |
Ductile Iron |
Quality Warranty: |
18 Months |
Fire Fighting System Use Ductile Iron Worm Gear Operated
Product introduction:
Fire fighting valve products are control accessories on industrial and building pipelines. Fire fighting valve is the most important controlled accessory on industrial and building pipelines, normally consisting of valve body, opening and closing mechanism, and valve cover. Simple structure and reliable sealing.
Middle-line soft seal butterfly valve with level operation is the preferred conventional butterfly valve for for fire fighting pipeline use. The utility model has the advantages of simple structure, small flow resistance coefficient, near-straight flow characteristics, and is free of debris, in light weight, convenient to be installed, and small in driving torque. This valve can be used to cut off media and also to regulate the flow of media used. Its actuating device can be upgraded according to user's requirements, such as worm gear operation, electric and pneumatic actuator etc.
Product technical parameter:
| Nominal Diameter DN (mm) | 50~200 | |
| Nominal Pressure PN (MPa) | 1.6 | |
| Test Pressure (MPa) | Strength (water) | 2.4 |
| Enclose (Water) | 1.76 | |
| Working temperature | 0~80℃ | |
| Medium suitable | Water | |
Product features:
1. Simple structure, compact design, small operating torque and fast opening by only rotating 90 degrees;
2. Internal leakage point is eliminated by connecting valve plate with valve rod without pin;
3.The encircle of valve plate is made as ball to improve the sealing performance and prolong the service life of valve, and there is zero leakage after the valve has been opened and closed for 50,000 times under pressure;
4.Sealing element can be replaced, and suitable for two-way seal box.
5.Clamp connection makes installation to pipeline process simple, fast, and convenient.
