Electric butterfly valve

Product Details

Place of Origin: China

Payment & Shipping Terms

Minimum Order Quantity: 1set

Packaging Details: Plywood box safety packing

Delivery Time: 14 days

Payment Terms: L/C,T/T,Western Union

Supply Ability: 100pcs per month

Get Best Price

Product Details

Product Description

Highlight:

Application::	General	Medium Type::	Water, Steam And Oil Etc.
Mounting Type::	Direct Mount	Standard Or Non-Standard::	Standard
Flow Way::	Two Way	Actuation::	Manual, Electric, Pneumatic,Automatic
Sealing Performance::	Sealing	Working Temperature::	Normal Temperature And High Temperature
Pressure Application::	Normal Pressure	Quality Warranty::	18 Months

Application::	General
Medium Type::	Water, Steam And Oil Etc.
Mounting Type::	Direct Mount
Standard Or Non-Standard::	Standard
Flow Way::	Two Way
Actuation::	Manual, Electric, Pneumatic,Automatic
Sealing Performance::	Sealing
Working Temperature::	Normal Temperature And High Temperature
Pressure Application::	Normal Pressure
Quality Warranty::	18 Months

Electric butterfly valve

Highlight: Electric butterfly valve

Product introduction:

The Electric Stainless Steel Butterfly Valve D971F (Electric Stainless Steel Wafer Butterfly Valve/Electric Stainless Steel PTFE Sealed Butterfly Valve/Electric Stainless Steel Rubber Sealed Butterfly Valve/Electric Stainless Steel Wafer-Type Butterfly Valve) features a compact design, lightweight construction, reliable performance, simple configuration, and high flow capacity. It is particularly suitable for applications involving viscous, particulate, or fibrous media. Widely used in industrial automation systems across various sectors including food processing, environmental protection, light industry, petroleum, paper manufacturing, chemical engineering, educational and research equipment, and power generation.

Product technical parameters:

Type number		D971F-16P
Nominal Diameter DN(mm)		50～1200
Nominal Pressure PN(MPa)		1.6
Control method		Electricity: On/off switch
Power supply		AC380V
Main parts	Valve body	Stainless steel 304 (CF8)
	Disc	Stainless steel 304 (CF8)
	Valve seat	PTFE
	Axle	Stainless steel 304 (CF8)
Medium suitable:		Water, air, oil and nitric acid etc corrosive medium
Working temperature		150≤℃
Connection type		Wafer type

Product features:

The electric stainless steel butterfly valve body requires only a small installation space, and its working principle is simple and reliable.
The electric stainless steel butterfly valve has a high flow capacity, with minimal pressure loss through the valve.
The electric stainless steel butterfly valve offers significant economic advantages, especially for larger-diameter models.
The valve body is compatible with standard raised-face pipe flanges.
Its nearly equal-percentage flow characteristic makes it suitable for both regulating and on-off control applications.
The special valve seat seal is suitable for clean liquid and gas media.
