Product Details
Place of Origin: CHINA
Brand Name: JGPV
Model Number: 400X-JGPV
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: USD74.9/Set - 4889.9/Set
Packaging Details: Plywood box safety packing
Delivery Time: 14 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000pcs per month
Standard Or Non-standrd: |
Standard |
Application: |
General |
Product Function: |
Water Supply Direction Regulation |
Construction: |
Diaphragm And Piston Type |
Working Temperature: |
Normal Temperature |
Pressure Application: |
Nomal Pressure |
Power: |
Hydraulic |
Manufacturing Craft: |
Casting |
Body Material: |
Ductile Iron, Cast Steel And Stainless Steel |
Quality Warranty: |
18 Months |
Name: |
Hydraulic Water Control Valve |
Standard Or Non-standrd: |
Standard |
Application: |
General |
Product Function: |
Water Supply Direction Regulation |
Construction: |
Diaphragm And Piston Type |
Working Temperature: |
Normal Temperature |
Pressure Application: |
Nomal Pressure |
Power: |
Hydraulic |
Manufacturing Craft: |
Casting |
Body Material: |
Ductile Iron, Cast Steel And Stainless Steel |
Quality Warranty: |
18 Months |
Name: |
Hydraulic Water Control Valve |
Ductile Iron Flow Control Valve For Water Supply Direction Regulation
Product introduction:
The 400X flow control valve is a valve used in a parallel water supply system for firefighting and domestic use, to regulate the direction of water supply. The 400X flow control valve consists of a hydraulic control connecting system consisting of a main valve, a flow regulating valve, a needle valve, a guide valve, a ball valve, a micro filter, and a pressure gauge. By utilizing hydraulic automatic operation, the opening of the main valve is controlled and adjusted to maintain a constant flow rate through the main valve. It utilizes hydraulic self control and does not require other devices or energy. It is easy to maintain and has stable flow control. This valve product is widely used in water supply network systems such as high-rise buildings and residential areas, as well as urban water supply engineering.
Product technical parameter:
| Nominal Diameter DN (mm) | 50~300 | |
| Nominal Pressure PN (MPa) | 1.6/2.5 | |
| Test Pressure (MPa) | Strength (water) | 2.4/3.8 |
| Enclose (Water) | 1.8/2.8 | |
| Open and close pressure difference | ≤0.1MPa | |
| Working temperature | 0~80℃ | |
| Medium suitable | Water | |
Product features:
The 400X flow control valve is an excellent manager of flow and pressure, exerting its multifunctional charm in various pipelines in a high-precision pilot style. It is like a professional butler, carefully controlling flow and pressure, always keeping the predetermined flow constant, limiting excessive flow to a predetermined value, and appropriately reducing upstream high pressure. Even if there is a change in upstream pressure, it can ensure the stability of downstream flow and prevent the main valve from being affected in the slightest.
