Anti-Corrosion Eccentric Plug Valve with Flange Type Design for Reliable Sealing Performance

Product Details

Place of Origin: China

Brand Name: JGPV

Payment & Shipping Terms

Minimum Order Quantity: 1set

Packaging Details: Plywood box safety packing

Delivery Time: 14 days

Payment Terms: L/C,T/T,Western Union

Supply Ability: 500 Set per month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                Anti-Corrosion Eccentric Plug Valve, Eccentric Design Plug Valve, Flange Type Plug Valve


Application::	General	Certificate::	ISO9001, ISO14001
Medium Type::	Water, Steam And Oil Etc.	Connection::	Threaded / Flanged / Welded
Standard Or Non-Standard::	Standard	Flow Way::	Two Way
Actuation::	Manual, Electric, Pneumatic,Automatic	Sealing Performance::	Sealing
Working Temperature::	Normal Temperature And High Temperature	Pressure Application::	Normal Pressure
Quality Warranty::	18 Months

Application::	General
Certificate::	ISO9001, ISO14001
Medium Type::	Water, Steam And Oil Etc.
Connection::	Threaded / Flanged / Welded
Standard Or Non-Standard::	Standard
Flow Way::	Two Way
Actuation::	Manual, Electric, Pneumatic,Automatic
Sealing Performance::	Sealing
Working Temperature::	Normal Temperature And High Temperature
Pressure Application::	Normal Pressure
Quality Warranty::	18 Months

Anti-Corrosion Eccentric Plug Valve with Flange Type Design for Reliable Sealing Performance

XF5900B Ball Type Anti-Corrosion Eccentric Plug Valve

Product Overview

The XF5900B ball type anti-corrosion eccentric plug valve combines multiple advantages of domestic and international eccentric plug valves. It features an attractive design, flexible operation, easy maintenance, excellent sealing performance, large flow area, and low flow resistance. The welded Ni-sealed valve seats provide reliable corrosion and wear resistance, making it suitable for harsh water and oil applications.

Technical Specifications

Model No.	PN (MPa)	Test PS (MPa)	Application	Working Temperature (℃)
XF5900B-10	10	1.5	Clear water, sewage, oil products	≤80
XF5900B-16	16	2.4	Clear water, sewage, oil products	≤80

Key Features

Double eccentric design for low friction operation and zero leakage
90% nickel content, 3mm thick welded valve seat or high-performance resin seat for corrosion resistance
V-shaped combination sealing ring, replaceable without removing operating device
Sealant filling port design extends valve service life
Self-lubricating valve bearing material eliminates need for grease, minimizing shaft wear
Hot-sealed rubber molded plug body prevents rubber detachment and erosion corrosion
O-ring sealed valve cover-body connection reduces bolt count for easier maintenance
Pressure gauge connectors provided for flow measurement and control

Product Images
