Worm Gear Actuator Butterfly Valve Ductile Iron Wafer Type For Low Pressure Pipeline Applications

Name: Worm Gear Actuator Butterfly Valve Ductile Iron Wafer Type For Low Pressure Pipeline Applications
Brand: Shanghai Jianggong Valve Manufacturing Co., Ltd.
SKU: D371X-16Q
Price: 41.90 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: JGPV

Model Number: D371X-16Q

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: USD14.9/PC - USD69.9/PC

Packaging Details: Plywood box safety packing

Delivery Time: 14 days

Payment Terms: L/C,T/T,Western Union

Supply Ability: 1000pcs per month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                ductile iron butterfly valve, low pressure wafer butterfly valve, worm gear actuator butterfly valve


Name:	Worm Gear Actuator Butterfly Valve Ductile Iron	Application:	Industrial Usage, Water Industrial Usage
Standard:	ANSI, ASME, DIN, GB	Medium Type:	Water, Oil
Manufacturing Craft:	Casting	Flow Direction:	Two Ways
Working Temperature:	Normal Temperature	Pressure Application:	Low Pressure
Port Size:	DN40-DN300	Test Standard:	Strength Test And Sealing Test And Other Test Clients Need
Quality Warranty:	18 Months

Name:	Worm Gear Actuator Butterfly Valve Ductile Iron
Application:	Industrial Usage, Water Industrial Usage
Standard:	ANSI, ASME, DIN, GB
Medium Type:	Water, Oil
Manufacturing Craft:	Casting
Flow Direction:	Two Ways
Working Temperature:	Normal Temperature
Pressure Application:	Low Pressure
Port Size:	DN40-DN300
Test Standard:	Strength Test And Sealing Test And Other Test Clients Need
Quality Warranty:	18 Months

Worm Gear Actuator Butterfly Valve Ductile Iron Wafer Type For Low Pressure Pipeline Applications

Worm Gear Actuator Butterfly Valve Ductile Iron Wafer Type For Pipeline

Product Overview

Worm Gear Actuator Driven Ductile Iron Wafer Type Concentric Butterfly Valve

Concentric butterfly valve with soft seal is the preferred conventional butterfly valve for pipeline applications. This valve features simple structure, minimal flow resistance coefficient, near-straight flow characteristics, and is free of debris accumulation. It offers lightweight construction, easy installation, and requires minimal driving torque.

The concentric butterfly valve can be operated with various types of actuators according to user requirements, including manual, electric, pneumatic, or other forms. Worm gear operation provides easy handling and is the most common operational type. Different materials and seal rings are available to suit various media and working conditions, ensuring optimal cost-performance matching.

The soft seal butterfly valve is suitable for temperatures below 120°C and nominal pressures below 1.6 MPa. It is ideal for industries including water supply and drainage, sewage, food processing, heating, gas, shipping, hydro-power, metallurgy, energy systems, and textiles. Particularly suitable for two-way seal box valve bodies that are prone to rusting.

Technical Specifications

Parameter	Specification
Nominal Diameter DN (mm)	50~300
Nominal Pressure PN (MPa)	1.6
Test Pressure (MPa)	Strength (water): 2.4 Enclose (Water): 1.76
Main Components	Valve body: QT450 Disc: QT450, CF8, CF8M etc. Seat: EPDM, NBR, PTFE, VITON etc. Axle: 2Cr13
Working temperature	≤120℃
Medium suitable	Water and oil
Connection	Wafer type

Product Features

Compact and portable design, easy to remove and maintain, installable in any position
Linear flow characteristics with excellent regulating performance
Simple structure, compact design, minimal operating torque, and fast 90-degree opening
Eliminated internal leakage points through pinless connection of valve plate with valve rod
Ball-shaped valve plate encirclement improves sealing performance and extends service life
Zero leakage after 50,000 pressure cycles of opening and closing
Replaceable sealing elements suitable for two-way seal box applications
Customizable butterfly disc painting available upon request
