Digital Locking Hydraulic Flow Control Valve with Threaded Brass and Low-Temperature Static Balance Cut-off Valve

Product Details

Place of Origin: China

Brand Name: JGPV

Payment & Shipping Terms

Minimum Order Quantity: 1set

Packaging Details: Plywood box safety packing

Delivery Time: 14 days

Payment Terms: L/C,T/T,Western Union

Supply Ability: 500 Set per month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                Digital Locking Static Balance Valve, Threaded Brass Cut-off Valve, Low-Temperature Flow Control Valve


Application::	General	Certificate::	ISO9001, ISO14001
Medium Type::	Water, Steam And Oil Etc.	Connection::	Threaded / Flanged / Welded
Standard Or Non-Standard::	Standard	Flow Way::	Two Way
Actuation::	Manual, Electric, Pneumatic,Automatic	Sealing Performance::	Sealing
Working Temperature::	Normal Temperature And High Temperature	Pressure Application::	Normal Pressure
Quality Warranty::	18 Months

Application::	General
Certificate::	ISO9001, ISO14001
Medium Type::	Water, Steam And Oil Etc.
Connection::	Threaded / Flanged / Welded
Standard Or Non-Standard::	Standard
Flow Way::	Two Way
Actuation::	Manual, Electric, Pneumatic,Automatic
Sealing Performance::	Sealing
Working Temperature::	Normal Temperature And High Temperature
Pressure Application::	Normal Pressure
Quality Warranty::	18 Months

Digital Locking Hydraulic Flow Control Valve with Threaded Brass and Low-Temperature Static Balance Cut-off Valve

Digital Locking Hydraulic Flow Control Cut-Off Valve

Low-temperature threaded thickened brass static valve for industrial and commercial heating systems

Product Overview

Our digital lock balance valve is an advanced energy-saving valve with specialized functionality. Featuring digital display and locking mechanisms, this valve enables precise adjustment to any position and includes pressure measurement capabilities for flow monitoring. Primarily designed for industrial and civil building heating pipeline systems, it offers superior flow characteristics, accurate pressure drop and flow rate adjustment, and efficient flow distribution.

Technical Specifications

Parameter	Specification
Model	SP45F-16Q
Test Pressure	2.4 MPa (24 kgf/cm²)
Working Pressure	≤1.6 MPa (16 kgf/cm²)
Operating Temperature	-10℃ to 100℃
Compatible Medium	Water
Characteristic Curve	Equal Percentage
Installation Scope	Main trunk lines, branch trunks, indoor water supply mains, branch risers, and multiple boiler pipeline systems

Installation Requirements

Install sufficient length of branch pipe sections before and after the static balance valve to ensure rated flow rate output
Verify installation position according to drawings, typically on HVAC system return pipelines
Confirm water flow direction and install strictly following the flow arrow direction on valve body
Thoroughly clean pipeline debris before installation - prohibit welding slag, branches, stones, or other debris
Avoid excessive deformation and welding angles during pipeline flange welding that could affect sealing surface flatness
After installation, fully open valve for repeated pipeline flushing until clean - do not repeatedly close valve during flushing

Product Images
